  • Vacuum SMT Reflow Oven KC-Z104
Vacuum SMT Reflow Oven KC-Z104

Vacuum SMT Reflow Oven KC-Z104

  • PCB: 400mm*350mm
  • 10 heating zones
  • Weight APPROX:2500KG
  • Dimension L6025×1350×1500mm
  • Product description: Vacuum SMT Reflow Oven KC-Z104,China factory manufacturer directly. PCB: 400mm*350mm, 10 heating zones, Weight APPROX:2500KG, Dimension L6025×1350×1500mm
  • INQUIRY

Vacuum SMT Reflow Oven KC-Z104

Specifications:


Vacuum SMT Reflow Oven KC-Z104

The Vacuum Reflow Oven Soldering theory is make a vacuum environment at the soldering area, this makes the solder nearly no void after soldering.

Features:

Model

KC-Z104

Weight

APPROX:2500KG

Dimension

L6025×1350×1500mm

Heating zone qty.

Top10/ bottom 10

Cooling zone qty.

Top 4/ bottom 4

Cooling way

Forced water cooling

Rectifying plate structure

Carbon heating plate

Exhausting requirement

10/min×2

Control system

Power supply

3P 380V 50/60HZ

Total power

54KW

Startup power

38KW

Consumption power

12KW

Speed adjusting

3 sections with 3 inverters

Warm up time

Apprx.20minute

Temp. control range

Room temp.300℃ (adjustable)

Temp. control accuracy

±1℃

PCB temp. deviation

±1.5℃

Data store

Can store unlimited setting parameters

Abnormal alarm

High temp., low temp., conveying, vacuum pressure,   nitrogen, air volume, PCB entering abnormal

Conveying system

Rail structure

Separately controlled in 3 sections

PCB   max. width

400mm*350mm

Conveyor height

900±200MM

Conveying way

Chain

Vacuum system

Vacuum min. pressure

0 .1MP

Vacuum pump power

3KW rotary vane wet

Vacuum pressure relief time

10S

Vacuuming time

10-300S

Vacuum chamber open way

Electric

Vacuum chamber size

500*400*300mm

Production beat

20S

Nitrogen system (option)

Nitrogen period

The whole production time

Nitrogen concentration

500-1000PPM

Nitrogen consumption

15-30m³

After use our Vacuum reflow oven, Customer's high end PCB void rate is less than 1%, Customer are very satisfied on the effect.

Keywords:

SMT Reflow Oven, Nitrogen Reflow Oven, Dual Lane Reflow Oven, Vertical Reflow Oven, Vacuum SMT Reflow Oven, Lead free SMT Reflow Oven, Reflow Oven Manufacturer, LED Reflow Oven, China Reflow Oven.

Flason Electronic Co.,ltd provide a full SMT assembly line solutions, including SMT Reflow OvenWave Soldering MachinePick and Place MachineSMT Stencil PrinterSMT AOI SPI MachineSMT Reflow OvenSMT Peripheral EquipmentSMT Assembly lineSMT Spare Parts  etc any kind SMT machines you may need, please contact us for more information: wechat whatsapp:+8613691605420, Skype: flasonsmt, Email: tommy@flason-smt.com
